MARATHON
High quality with high sensitivity UV CTCP Plates.
Marathon CTCP Plate
Description
Marathon CTCP plates are a new generation of UV-CTP plates that have been developed specifically for the Indian Printing Industry. The formulation is such that it meets the market requirements for speed and efficiency. The production process is highly stable giving consistent quality in terms of performance of plates during printing.
Marathon CTCP plates are the best choice for offset packaging and commercial printing with features of high sensitivity, capability to reproduce up to 20m stochastic screen, and long run length: 100,000 impressions with normal ink.
Characteristics
Highest quality aluminum plate
Complex grain structure & dense oxidized layer
Perfect coating formulation
Stable for sheet-fed and commercial web for medium-long runs
Possibility to post-bake to increase run length
Wide developing latitude
Excellent performance on press
Compatible with all conventional developers.
Technical Specifications
Plate Type
High quality with high sensitivity UV CTCP plate
Application
Commercial sheet-fed and rotary press offset printing
Substrate
Electrochemically grained and anodized aluminum
Gauge
0.15/0.20/0.25/0.30 mm
Coating Color
Blue
Spectral Sensitivity
405 nm
Laser Energy
50-55 mJ/cm2
Resolution
2- 98% @ 200 lpi
Applicable Platesetter
Major UV-CTP platesetters such as Cron, Eastom, Luscher, Amsky, BasysPrint.
Processing
25 - 5 seconds dwell time at temperature 25 - 1C
Run Length
100,000 impressions unbaked
300,000 impressions post baking
(Actual run length may vary according to press, ink and paper conditions)
Safelight
Yellow light
Shelf life
18 months under recommended storage conditions
Packaging
Available in all standard formats
Transport and Storage
Unopened plate packs should be stored at and away from excessive cold, heat
Store in a controlled environment of 15 - 27C and 40% - 65% RH, non- condensing
